BOL-BTG9516

• 16-Channel Inputs
• H.264 Video Compression
• PTZ Control
• IP Hybrid DVR, Supports AHD / TVI / CVI/ Analog Formats
• Records Up to 1080p Output,
• HDMI and VGA Outputs
• 4-Channel Audio In/ 1-Channel Audio Out
• 2 SATA Hard Drive Bay Up to 16TB
• Offers QuickConnect




Specifications:

Record Resolution:	PAL:720P/1080P NTSC:720P/1080P
Record Speed:	PAL:1080P @15fps(each ch) / 720P@25fps(each ch) NTSC: 1080P @15fps(each ch) / 720P @30fps(each ch)
Display Resolution:	PAL:720P/1080P@25fps(each ch) NTSC:720P/1080P@30fps(each ch)
Video Compression:	H.264
Video System:	NTSC/PAL
Operating System:	Embedded Linux
Analog Video Input/Output:	16CH inputs/VGA& HDMI output
Audio Input/Output:	4CH inputs / 1 CH output (RCA)
Alarm Input/Output:	16CH Input / 1 CH Output
Recording Mode:	Continuous/Manual/Motion detect
Simultaneous Playback:	Local DVR: 1~16ch PC/MAC: 1~4ch Smart Phones: 1ch (using app) Tablets: 1~4ch
USB:	2 x USB (for mouse and backup)
PTZ Control:	Yes (RS485) Control over Coax
VGA:	800x600,1024x768, 1280x1024,1440x900, 1920x1080
HDMI:	1080P
HDD:	2 x SATA, Up to 12TB per bay
Multiplex Operation:	Live display, record, playback, backup, and network
Network Protocol:	Lan, DHCP and DDNS
Voltage:	12VDC / 5Amps
Working Temp:	-10°C ~ 55°C
Humidity:	10% ~ 90% Humidity
Dimension:	380 x 340 x 53mm (15 x 13.4 x 2in)
