Features:

For Offices, Schools, Hospitals, Apartments, Hotel / Motel, Residential, Commercial and Public Buildings

Interchangeable core users can enjoy the convenience of fast rekeying without having to disassemble the lock. This feature is very useful in applications where a high frequency of core changes are needed.

ANSI Function F109 – Turn/Push button locking. Pushing and turning button locks outside lever requiring use of key until button is manually unlocked. Pushing button locks outside lever until unlocked with key or inside lever is turned.

• Heavy-Duty, BHMA/ANSI Grade 1 certified
• Small format interchangeable core prep (core sold separately)
• ADA compliant, 3-hour fire-rated
• Clutch mechanism, fixed thru-bolt installation



Specifications:

Collection	Cal-Royal
Handing	Non-Handed
Function	Entrance / Office Lock
Finish	626 - Satin Chrome
Backset	2-3/4"
Door Thickness	1-3/8" - 1-3/4"
Strike	1-1/4” x 4-7/8”
Latch Faceplate	Standard 2-1/4" x 1-1/8" for 2-3/4" backset
Cylinder	Interchangeable Core locks will accept compatible 6 or 7 pin cores with BEST, FALCON and ARROW
Keyway	KW
Certification	ANSI/BHMA A156 2 Series 4000 Grade 1



Downloads:

• Catalog
• Installation Instructions
