CDL-KL1060

Activate > Generate > Control

NetCode® is the smart way to generate time-sensitive codes for a wide range of lockers and cabinets.

Through the online Codelocks Connect Portal or via the Codelocks simple API (application programming interface), you can create codes that have a specified start date, time and duration. Once the duration expires, the codes no longer work. Using time-sensitive codes is a more secure way to grant access as the code will not work outside a designated timeslot. Issue codes to visiting service engineers, delivery personnel (drop boxes), and medium-term locker rental. Generated codes can be sent by email or SMS.

Features:

• No wired or wireless communication required
• Create codes for short, medium and long-term
• Web-based NetCode^® generation
• Send generated codes via email or SMS**
• Three modes of operation
• Five types of NetCode^®
• Additional NetCode^® features
• 15,000 operations from 2 x AAA batteries
• 11 button keypad
• Master Code
• Sub-Master Code
• User Code
• Technician Code
• NetCode^®
• Battery override
• Easy to install and set up
• IP55 rated when fitted with gasket
• Not suitable for a Chlorine environment
• All parts / fixings / templates included
• Two year guarantee

Functions:

Codelocks NetCode^® Technology

This function allows temporary access. Create time-sensitive codes via the Codelocks Connect Portal or your own application with Codelock's simple API (application programming interface).

 Private Function

This is the most common function and used where the same code will be repeatedly used, e.g. a pupil in a school or an employee with the same locker in the workplace.

Public Function

In this function the KitLock operates with a single User Code. The user enters their own personal four-digit code. This locks the lock. The same code is entered once only to open the lock before being erased and ready for the next new user. This function is used for short term, multi occupancy applications, e.g. a locker in a leisure center.

---

Types of NetCode

Five types of NetCode are available:

• Short-term multi-use codes with durations from 1 to 12 hours and 1 to 7 days
• Short-term single-use codes with durations from 1 to 12 hours and 1 to 7 days
• Medium-term codes with durations from 1 to 21 days + 28 days
• Long-term codes that work for periods of up to 1 year
• Codes that will expire on a particular date

Additional NetCode Features

• New NetCode Blocks Previous NetCode
• This feature automatically blocks the last used NetCode when a new NetCode is entered.
• Mode Restrictions
• Choose which types of NetCode to support. This is a useful feature if the number of potentially available NetCode modes needs to be reduced.
• Block a NetCode
• Block a NetCode directly on the lock using either the Master Code or another valid NetCode.
• Person User Code
• Allow a NetCode user to create a personal 4 digit number that retains the same validity period as their originally allocated NetCode.

Specifications:

Brand	KitLock by Codelocks
Battery Override	A 9 volt PP3 battery can be placed against external contacts
Code Change Method	Keypad (On Door)
Buttons	2 x 5 + Programming
Door Thickness	Ready to fit doors up to 1" (25mm)
Finish	Silver
Functions	Private, Public, NetCode®
Keypad	11 individual round buttons
Lock Dimensions	5 3⁄8" (136mm) x 11⁄16" (28mm) x 15⁄16" (33mm)
Low Battery	Red LED will flash 3 times before unlocking
Latch Type	Cam
Memory	Non-volatile memory will be retained
Operations	Up to 15,000 opening per 2 x AAA batteries
Power	2x AAA
NetCode	Standard (Multi Use), Standard (Single Use), Rental 365, Rental 1 - 21 Days
Orientation	Vertical, Left Handed, Right Handed
Suitable For	Internal, External
User Levels	Master, Sub Master, Technician, User
User Types	Code, NetCode





Downloads:

• Brochure
• Installation Instructions
• Programming Instructions
• Switching NetCode Modes
