The Gaab 360  Series exit devices are well-suited for various door needs, ranging from light to medium duty, including in commercial, residential, office, and retail settings. These Grade-1 exit devices provide affordability without compromising on quality, available in various functions, lever styles, and trim options. Opting for the Gaab 2000 Series means selecting a high-performing medium-duty exit device crafted entirely from metal, delivering exceptional value.

Features:

• Rim Exit Device
• Suitable for Narrow Stile Door
• Conforming ANSI/BHMA A156.3- 2014 Grade 1
• Fire-Rated Model 3-Hour
• 40" Nominal length for 42" Door
• Device can be cut up to 27"
• Outside trim needed, T840 series recommended
• Size of head 6" (153mm) x 1.5" (40mm) W for a minimum of 3" stile door
• Easy installation

Specifications:

Brand	Gaab locks
L/W/H	42" x 6" x 2"
Weight	4 Lbs
Usage	Narrow Stile for Heavy Duty Usage
Finish	Satin Stainless Steel
Trim	Compatible with Gaab T840 & G8900 Series
Masterbox	42" x 14" x 12" 6pcs 24lbs
Hand	Field Reversible
Comparable to	Hager 4700 - Design hardware 2000 - Falcon 20
Warranty	5-Years Warranty
UL listed	Yes
UL 3 Hours Fire Rated	Yes
Applicability	Can be used for left and right-hand doors
Accessories	Fixing screws, end cover, striker
Passed Durability Test	500,000 cycles



Some of the compatible exit trims include:
GAB-T840M14
GAB-T840M15
GAB-T840M16
GAB-T840M17
 As well as exit trims from other brands like Kenaurd, Tell & Townsteel





Downloads

• Spec Sheet
• Instructions Manual
• Warranty
