The Lockly Duo Compact is an interconnected smart lock that combines a deadbolt and latch into one seamless design, allowing for quick and easy access with a single lever motion. It features Lockly's hack-proof PIN Genie keypad, fingerprint access, and smartphone control for enhanced security and convenience. With the included Secure Link WiFi Hub, you can integrate voice assistants and remotely monitor or control your door 24/7 from anywhere in the world.

Key Features:

• Two Locks in One: Dual Locking Technology secures both latch and deadbolt with a single motion.
• AI Biometric Fingerprint: Stores up to 99 fingerprints, improving accuracy with each use.
• Hack-Proof Touchscreen: PIN Genie® keypad shuffles numbers after each use to prevent guessing.
• App Remote Control: Unlock, monitor, and manage access through the Lockly app.
• Grant Access Without Internet: Generate one-time or recurring Offline Access Codes.
• Voice Control: Works with Amazon Alexa and Google Assistant.
• Auto Locking: Programmable auto-lock ensures your door is always secured.
• Mechanical Keys: Two backup keys included with easy rekeying capability.
• DIY Installation: Can be installed as a mortise retrofit or deadbolt/lever handle replacement.
• Best-in-Class Support: 5-year mechanical & finish warranty, 2-year electronics warranty, lifetime support.

What's Included:

• Lockly Duo Compact Smart Lock
• Secure Link Wi-Fi Hub
• Quick Start Guide
• Installation Guide
• User Manual
• 4x AA Alkaline Batteries
• Drilling Template
• Activation Card
• 2x Physical Keys
• Wired Door Sensor
• Deadbolt and Latchbolt
• Cover Plate x2
• Interconnection Plate
• Fixing Screws
• Strike Plate

Specifications:

Access Codes	Stores up to 33 PIN access codes
Fingerprint Access	Stores up to 99 biometric fingerprints
Remote Access	Unlimited Offline Access Codes & eBadges
Access Logs	Unlimited, accessible via Lockly app
Communication Standards	BLE 4.2, Wi-Fi 2.4GHz, RF433.92MHz, AES 256-bit encryption
Gateway Communication Range	98' (30m) BLE, 197' (60m) Wi-Fi, 164' (50m) RF433.92MHz
Battery Life	Up to 1 year (offline mode), 10 months (with app & sensor), 9V backup power socket
Operating Temperature	-4°F to 151°F (-20°C to 66°C)
Operating Humidity	0-100% non-condensing

Credential Specifications:

Credential Technologies	BLE (2.4 GHz), Wi-Fi (2.4 GHz), Capacitive Sensor, PIN Genie Keypad
Maximum Read Range	BLE: 98' (30m), Wi-Fi: 197' (60m)
Mobile Compatibility	Lockly app BLE 4.2, LocklyOS, Matter

Mechanical Specifications:

Handing	Field reversible
Materials	All-metal chassis and escutcheon
Door Thickness	1-3/8" - 2” (35mm-50mm)
Backset	Adjustable 2-3/8" or 2-3/4" (60mm or 70mm)
Physical Keys	SC1 Re-keying compatible, 2pcs included

Certifications/Warranty:

Certification	RoHS, FC, ADA Compliant
Warranty	Lifetime 24/7 Technical Support, 5-year Mechanical & Finish, 2-year Electronics

Downloads:

• iPhone App / Android App
• Spec Sheet
• User Manual
• Installation Guide

Installation Video:
