Command Access - ML371 Series - Electrified Sargent 8200 Series Mortise Lock - Storeroom - (EU) Outside Lever Unlocked Electronically - 24V Voltage - Right Handed

Product image 1
1 / 2

Command Access - ML371 Series - Electrified Sargent 8200 Series Mortise Lock - Storeroom - (EU) Outside Lever Unlocked Electronically - 24V Voltage - Right Handed

The Command Access ML371-24V-RH is a heavy-duty, electrified mortise lock body designed to retrofit Sargent 8200 series locks. It features fail-secure (electrically unlocked/EU) operation, operates on 24V AC/DC, and is configured for right-handed doors.

Features:

  • Fail-Secure Mode: The outside lever remains locked when power is removed, and the latchbolt can be retracted by a key outside or the lever inside (the inside lever is always free for immediate egress).
  • Low Current Draw: Features continuous-duty solenoids that allow for "continuously on" applications.
  • Bridge Rectifier: Includes a plug-in bridge rectifier to seamlessly support AC or DC power sources.

Specifications:

Cylinder Type Prepared For Mortise Cylinder
Locking State  Fail-Secure (Power To Unlock)
Function  Storeroom
Grade  ANSI Grade 1
Keyway  Less Cylinder
Product Type  Electrified Mortise Lock
Solenoid Duty  Continuous Duty
UL Listing  UL Listed
Voltage  Selectable 24V AC or DC
Handing  Right Handed (RH)
Power Draw  8W consumption, 350mA at 24V
Compliance  ANSI/BHMA Grade 1, UL Listed



Downloads:

$199.50

Original: $570.00

-65%
Command Access - ML371 Series - Electrified Sargent 8200 Series Mortise Lock - Storeroom - (EU) Outside Lever Unlocked Electronically - 24V Voltage - Right Handed—

$570.00

$199.50

Product Information

Shipping & Returns

Description

The Command Access ML371-24V-RH is a heavy-duty, electrified mortise lock body designed to retrofit Sargent 8200 series locks. It features fail-secure (electrically unlocked/EU) operation, operates on 24V AC/DC, and is configured for right-handed doors.

Features:

  • Fail-Secure Mode: The outside lever remains locked when power is removed, and the latchbolt can be retracted by a key outside or the lever inside (the inside lever is always free for immediate egress).
  • Low Current Draw: Features continuous-duty solenoids that allow for "continuously on" applications.
  • Bridge Rectifier: Includes a plug-in bridge rectifier to seamlessly support AC or DC power sources.

Specifications:

Cylinder Type Prepared For Mortise Cylinder
Locking State  Fail-Secure (Power To Unlock)
Function  Storeroom
Grade  ANSI Grade 1
Keyway  Less Cylinder
Product Type  Electrified Mortise Lock
Solenoid Duty  Continuous Duty
UL Listing  UL Listed
Voltage  Selectable 24V AC or DC
Handing  Right Handed (RH)
Power Draw  8W consumption, 350mA at 24V
Compliance  ANSI/BHMA Grade 1, UL Listed
